Shenzhen Meiyuxin Technology Co., Ltd. [supply TI chips] TPS62993QRYTRQ1 3V to 10V, 3A, low IQ automotive synchronous step-down converter quality assurance brand new and original for sale in large quantities! ! !

Product Description:

The TPS62993QRYTRQ1 is an efficient, small, flexible, and easy-to-use synchronous step-down DC/DC converter. A selectable switching frequency of 2.5MHz or 1.0MHz allows the use of small inductors and provides fast transient response. The device supports high VOUT accuracy of ±1.5% over the entire operating temperature range and improves load transient performance with a DCS-Control topology. The wide input voltage range of 3V to 10V supports various nominal inputs such as 9V rail, single or multi-cell Li-Ion battery, 5V or 3.3V rail.

The TPS62993QRYTRQ1 can automatically enter power saving mode (if auto PFM or PWM is selected) at light loads to maintain high efficiency. Additionally, to provide high efficiency at very light loads, the device features a low 4µA typical quiescent current. AEE (if enabled) provides high efficiency over VIN, VOUT and load current ranges. The device includes a MODE/Smart-CONF input to program internal and external voltage dividers, switching frequency, output voltage discharge, and automatic power-saving mode or forced PWM operation.

Characteristic:

• AEC-Q100 Qualified for Automotive Applications:

– Temperature class 1: –40°C to +125°C, TA

– Device HBM ESD Classification Level 2

– CDM ESD classification level C4B

• Provides functional safety

– Documentation available for functional safety system design

• Extended TJ range: up to 165°C

• High efficiency DCS-Control topology

– RDS(ON): 62mΩ high side, 22mΩ low side

– Seamless PWM/PFM transition

– internal compensation

• 4µA Low IQ (Typical)

• Up to 3A Continuous Output Current

• Output Voltage Accuracy of ±1.5% Over Temperature

• Configurable output voltage options:

– 0.6V to 5.5V VFB External Voltage Divider

– VSET internal voltage divider

• 16 Voltage Options (0.4V to 5.5V)

• Increased flexibility through MODE/S-CONF pin

– 2.5 MHz or 1.0 MHz switching frequency

– Forced PWM or Auto PFM (Power Saving Mode) with dynamic mode change option

– Output discharge on and off

• No external bootstrap capacitor required

• Overcurrent and thermal protection

• 100% Duty Cycle Mode

• Precision Enable Input

• Adjustable Soft-Start and Tracking

• Power Good Status Output

• Pinout optimized for single layer routing

• Wettable 2.2mm × 2.0mm VQFN package with 0.5mm pitch

TPS62993QRYTRQ1 application:

• ADAS

• Body electronics and lighting

• Infotainment system and instrument cluster

• Hybrid, electric and powertrain systems
