Shenzhen Meiyuxin Technology Co., Ltd. [Internet of Things Module Agent] New sale ADS1115IDGSR 16-bit 860SPS 4-channel delta-sigma ADC analog-to-digital converter with PGA, oscillator, VREF, comparator, I2C! ! !

Product Description:

The ADS1115IDGSR devices (ADS111x) are 16-bit, I2C-compatible, high-accuracy, low-power analog-to-digital converters (ADCs) in ultra-small leadless X2QFN-10 and VSSOP-10 packages. The ADS111x devices feature a low-drift voltage reference and oscillator.

The ADS1115IDGSR also features a programmable gain amplifier (PGA) and a digital comparator. These features, combined with a wide operating supply voltage range, make the ADS111xADS111x ideal for the EMIRR +IN values of the OPAx189 at specific frequencies often encountered in power- and space-constrained sensor measurement applications.

The ADS1115IDGSR can perform conversions at data rates up to 860 samples per second (SPS). The PGA provides an input range from ±256mV to ±6.144V, enabling precise measurement of large and small signals. The ADS1115 has an input multiplexer (MUX) that enables two differential input measurements or four single-ended input measurements. Digital comparators are available for undervoltage and overvoltage detection in the ADS1114 and ADS1115.

The ADS1115IDGSR can operate in either continuous conversion mode or single-shot mode. In single-shot mode, these devices automatically power down after a conversion; thus significantly reducing power consumption during idle periods.

Characteristic:

• Ultra-small X2QFN package: 2mm × 1.5mm × 0.4mm

• Wide supply voltage: 2.0V to 5.5V

• Low current consumption: 150μA (continuous conversion mode)

• Programmable data transfer rate: 8SPS to 860SPS

• Single cycle stability

• Internal low drift voltage reference

• Internal oscillator

• I2C interface: Four pin selectable addresses

• Four single-ended inputs or two differential inputs (ADS1115)

• Programmable Comparators (ADS1114 and ADS1115)

• Operating temperature range: -40°C to +125°C

Application：

• Portable meters

• Battery voltage and current monitoring

• Temperature measurement system

• Consumer electronics products

• Factory Automation and Process Control
